Description
INGERSOLL RAND
PRESSURE SWITCH
Ingersoll Rand Part#: 56288772 & 56288772-02
Furnas Hubbell Part#: 69JF9LY2C
INGERSOLL RAND PRESSURE SWITCH W/ UNLOADER VALVE AND ON/OFF LEVER. 4-PORT. THIS SWITCH IS NOT AN EXACT FACTORY REPLACEMENT, BUT WILL REPLACE WITH MINOR MODIFICATIONS.
Features:
- 3 and 5 HP 200 PSI maximum
- Improved unloader valve design
- Several terminal options
- Optional bottom cable entry
- Various pipe locations
Specs:
- Cut-In PSI: 140
Cut-Out PSI: 175
PSI Open/Close: 140/175 psi
Differential: 30 to 40 psi
Size: 1/4″
Connection Type: Female NPT
